SIMBA 30 Technical Specifications
Engine Details
No. of Cylinder / Displacement (CC)
3 / 1318
Engine Power (hp)
29 (21.62 kW) @2800 ERPM
Max Torque (Nm)
82
Air Cleaner
Dry type with Clogging sensor
Transmission
Clutch
Single - Diaphragm
Transmission Config
9 Forward + 3 Reverse, Side Shift
Speed (Forward) - kmph
1.86 - 25.17
Speed (Reverse) - kmph
2.68 - 10.38
Differential Lock (Standard)
Yes
Control systems
Brakes Type
Oil Immersed Disc Brakes
Steering Type
Power Steering
PTO RPM
540 & 1000
Hydraulics & Tyres
Hydraulic Control Type
Automatic Depth & Draft Control
Lifting capacity (kg)
750
Front Tyre Size
180/85D12 / 5.00*12 (Narrow Track)
Rear Tyre Size
8.3*20 / 8.00*18 (Narrow Track)
Turning Radius (m)
2.4
Dimensions & Weight
Tractor Weight (kg)
920
Wheel Base (mm)
1490
Overall Width Minimum (mm)
1040 / 930 (Narrow Track)
Driver Seat Height Min (mm)
950
Usage Data In Various Applications
Sprayer
GearL3
ERPM2000
PTO RPM540
Electrostatic Sprayer
GearL2/M1
ERPM2600
PTO RPM540
Intercultivation with Rotavator
GearL2
ERPM2600
PTO RPM540
MB Plough 2B Reversible
GearM1
ERPM2000
PTO RPM-
Rotavator
GearL1/L2
ERPM2600
PTO RPM540
Puddling
GearL2
ERPM2600
PTO RPM540
Cultivator
GearH1/M2
ERPM1300-1500
PTO RPM-
Ridger
GearH1
ERPM1400-1600
PTO RPM-
Seed Drill
GearH1
ERPM1200-1300
PTO RPM-
